Medicine Processing Manufacturers Direct Selling Vibrating Fluid Bed Dryer Industrial Germ Vibrating Fluid Bed Dryer Salt Fluid Bed Dryer

1.0 Sets
MOQ
Medicine Processing Manufacturers Direct Selling Vibrating Fluid Bed Dryer Industrial Germ Vibrating Fluid Bed Dryer Salt Fluid Bed Dryer
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Fluid Bed Drying Equipment
Application: Medicine Processing, Chemicals Processing, Food Processing, Pharmaceutical Industry
Condition: New
Voltage: 220V/380V
Power: 1.5*2, 1.5*2kW
Dimension(L*W*H): 1286*6510*1940mm
Key Selling Points: High Productivity
Warranty: 1 Year
Weight (KG): 2410
Applicable Industries: Manufacturing Plant, Food & Beverage Factory, Farms, Food Shop, Construction Works , Energy & Mining, Pharmaceutical Industry
Showroom Location: None
Marketing Type: Ordinary Product
Machinery Test Report: Provided
Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year
Core Components: Other
Evaporation Capacity(kg/h): 20-300
Heating Method: ( Steam, Natural Gas, Electrical, Coal-fired ) Heating.
Material: SUS304, Other
ZG-6-60: Drying Machine
Working Size: 600*6000mm
Dimension: 1286*6510*1940mm
Weight: 2410kg
After-sales Service Provided: Online Support, Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service
After Warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location: None
Basic Infomation
Payment & Shipping Terms
Packaging Details: Standard wooden box packing for export
Supply Ability: 50 Set/Sets per Month
Product Description

Main application

Suitable for drying and cooling of powdery and granular materials in chemical, pharmaceutical, food, dehydrated vegetables, grain, minerals and other industries. Such as: salt, rice, citric acid, monosodium glutamate, borax, ammonium sulfate, compound fertilizer, shredded radish, soybean meal, vinasse, seeds, slag, sugar, etc.
PRODUCT PARAMENTERS
Model
Fluidized bed area（m2）
Inlet air temperature（℃）
Outlet temperature（℃）
Water evaporation capacity（kg/h）
Vibration motor
Model
Power(kw)
ZG-3-30
0.9
70-140
40-70
20-35
ZDJ31-6
0.8×2
ZG-3-45
1.35
70-140
40-70
35-50
ZDJ31-6
0.8×2
ZG-4-45
2.025
70-140
40-70
50-70
ZDJ32-6
1.1×2
ZG-6-45
2.7
70-140
40-70
70-90
ZDJ32-6
1.1×2
ZG-4-60
2.7
70-140
40-70
80-100
ZDJ41-6
1.5×2
ZG-6-60
3.6
70-140
40-70
100-130
ZDJ41-6
1.5×2
ZG-7.5-60
4.5
70-140
40-70
120-140
ZDJ42-6
2.2×2
ZG-6-90
5.4
70-140
40-70
140-170
ZDJ42-6
2.2×2
ZG-6-75
4.5
70-140
40-70
130-150
ZDJ42-6
2.2×2
ZG-7.5-75
5.625
70-140
40-70
150-180
ZDJ51-6
3.0×2
ZG-9-60
6.75
70-140
40-70
160-210
ZDJ51-6
3.0×2
ZG-12-75
9
70-140
40-70
200-260
ZDJ51-6
3.0×2
Model
A
B
C
D
E
F
Weight（kg）
ZG-3-30
3000
300
1350
900
430
1650
1250
ZG-3-45
4500
300
1350
900
430
1650
1560
ZG-4-45
4500
450
1550
950
430
1700
1670
ZG-6-45
4500
600
1650
950
430
1700
1910
ZG-4-60
6000
450
1650
950
430
1700
2100
ZG-6-60
6000
600
1700
1000
500
1700
2410
ZG-7.5-60
6000
750
1850
1000
600
1850
2340
ZG-6-90
6000
900
2000
1000
600
1850
3160
ZG-6-75
7500
600
1850
1000
600
1850
3200
ZG-7.5-75
7500
750
2000
1000
600
1850
3600
ZG-9-60
7500
900
2100
1000
600
1850
4140
ZG-12-75
7500
1200
2500
1150
800
2050
5190
PRODUCT DESCRIPTION
Working principle
The material enters the machine from the feed port. Under the action of vibration, the material is thrown along the
horizontal fluidized bed and moves forward continuously. After the hot air passes through the fluidized bed and exchanges heat with the wet material, the wet air passes through the cyclone separator to remove dust. It is discharged from the exhaust port, and the dry material is discharged from the discharge port.

Features of vibrating fluidized bed dryer:

1. The material is heated evenly, the heat exchange is sufficient, the drying strength is high, and the energy-saving is about 30% compared with ordinary dryers.
2. The vibration source is driven by a vibration motor, with stable operation, convenient maintenance, low noise and long life.
3. Stable fluidization, no dead ends and blow-through phenomenon. The opening form of the bed and the opening rate is important. The final moisture and output can be controlled by the amplitude and the amount of feed.
4. Good adjustability and wide adaptability.
5. It has little damage to the surface of the material, and can be used for drying fragile materials, and the work effect will not be affected when the material particles are irregular. Significantly better than fluidized bed.
6. The fully enclosed structure effectively prevents cross-contamination between materials and air, and the working environment is clean.
